Cork Sheet & Rubberised Cork Gasket Sheet
Technical Specification
| Material: | Granulated cork bonded with rubber (rubberised cork) or with a binder (plain cork) |
|---|---|
| Grades: | Nitrile (NBR)-cork for oils and fuels, neoprene-cork for general and weather duty, plain cork |
| Typical Thickness: | Approx. 1 mm to 12 mm |
| Supply: | Sheets, rolls and gaskets cut to drawing |
| Service: | Moderate temperatures and low pressures; confirm the rating for your grade |
| Note: | Figures are typical; confirm exact grade, size and rating with our team |
Why Use Cork Gaskets?
- Seals at low bolt load: ideal for thin covers and sheet-metal flanges that would bend under high bolt force
- Compressible: takes up uneven or distorted surfaces
- Oil resistance: nitrile-cork grades resist transformer oil, lubricants and fuels
- Vibration damping: reduces noise and vibration on covers and housings
Applications
- Transformer tank and inspection cover gaskets
- Gearbox, oil pan and valve cover gaskets
- Pump and compressor covers
- Electrical enclosures and junction boxes
- Anti-vibration pads and machine mounts
Rubberised Cork vs Plain Cork
Rubberised cork combines cork’s compressibility with rubber’s resilience and recovery, so it lasts longer and resists crumbling. Plain cork is economical for light, static covers. For oil-filled transformers and gearboxes, nitrile-cork is the usual choice.
Information to Send
- Grade (nitrile-cork, neoprene-cork or plain)
- Thickness and sheet size, or a gasket drawing
- Fluid and operating temperature
- Quantity
See also: Ready-Cut Gaskets, Rubber Sheets and Gaskets & Seal Materials.
Send us your sizes, quantities and service conditions (fluid, temperature, pressure) and our Al Khobar team will confirm availability, lead time and a quotation for delivery anywhere in Saudi Arabia and the GCC. Every order is supplied with a Material Test Certificate.
Frequently Asked Questions
Q1. What is rubberised cork sheet used for?
A. Gaskets for transformers, gearboxes, oil pans and covers that need a compressible seal at low bolt load.
Q2. Is cork sheet oil resistant?
A. Nitrile (NBR)-bonded cork resists transformer oil, lubricants and fuels. Plain cork is not recommended for oil.
Q3. What thickness of cork sheet is available?
A. Typically from about 1 mm to 12 mm. Contact us to confirm stock for your grade.
Q4. Can you cut cork gaskets to drawing?
A. Yes. Send a drawing or sample and we will quote cut gaskets.
