Spiral Wound & RTJ Gaskets – Product Details
As an SWG supplier in KSA, Diode Trading EST supplies spiral wound gaskets made from alternating windings of metal strip and soft filler, fitted with inner and outer rings to centre the gasket and control compression. They are the standard choice for raised-face flanges in process piping where temperature and pressure cycling would damage a plain sheet gasket.
We also stock ring joint (RTJ) metal gaskets for API 6A and ASME B16.5 / B16.47 ring-type-joint flanges used on wellheads, high-pressure pipelines and refinery units. Both ranges are supplied against ASME, API and EN flange standards, with material certificates from the manufacturer available on request.
- Spiral wound gaskets: CGI style (inner and outer ring), CG style (outer ring only), 1/2″ to 48″ nominal bore, Class 150 to 2500
- Winding metals: SS304, SS316L, Monel, Inconel, carbon steel rings
- Filler materials: flexible graphite, PTFE, mica for high-temperature service
- Ring joint gaskets: R, RX and BX profiles in soft iron, low-carbon steel, SS304, SS316 and F5
- Heat-exchanger, double-jacketed and kammprofile gaskets on request
- Applications: flanged piping, valves, pumps, heat exchangers, wellhead and pipeline flanges
Where it is used:
- Refineries and petrochemical plants in Jubail and Yanbu
- Oil and gas production facilities and pipelines in the Eastern Province
- Power and desalination plants along the Gulf and Red Sea coasts
- Fertilizer, chemical and gas processing plants
- EPC contractors and maintenance teams working on flanged piping systems
What is the difference between spiral wound and RTJ gaskets?
Spiral wound gaskets seal on raised-face flanges with a metal-and-filler winding; RTJ gaskets are solid metal rings that seat in a machined groove on ring-type-joint flanges, typically for higher pressures.
Do you stock standard flange sizes?
Yes. Common sizes and pressure classes are held in our Dammam warehouse; non-standard sizes can be sourced on request.
Can you supply material certificates?
Manufacturer material test certificates can be provided with the goods when requested at the time of ordering.
Spiral Wound and RTJ Gasket Supply from Dammam
Diode Trading EST is a ring joint and spiral wound gasket supplier in Saudi Arabia, serving plants, contractors and maintenance teams from our warehouse in Dammam. We are a trading and supply company: we source SWG and RTJ metal gaskets from established gasket manufacturers and hold them in stock so that routine shutdown and maintenance orders can be filled quickly rather than waiting on import lead times.
Our stock covers the sizes and pressure classes most often requested in the Eastern Province, including spiral wound gaskets with graphite or PTFE filler in SS304 and SS316L, and R, RX and BX ring joint gaskets in soft iron and stainless steel. Where a job calls for an unusual size, special filler or exotic alloy, we can source it through our supplier network and advise on a realistic delivery time.
Spiral wound and RTJ gaskets are supplied as finished items to the flange standard and rating you specify, so please share the flange size, class, facing type and service conditions when enquiring. If you are unsure which gasket type your flange needs, Read our buying guide for a plain explanation of styles, materials and selection points.
To order, send your list of sizes and quantities through our request a quote page, by email to sales@diode.sa, or on WhatsApp at +966 56 838 3649. Stock items are dispatched from Dammam to Al Khobar, Jubail, Riyadh, Jeddah and other cities across the Kingdom, and we export regularly to Bahrain, Qatar, Kuwait, the UAE and Oman.
Are you a manufacturer of spiral wound gaskets?
No. Diode Trading EST is a supplier and trader. We stock gaskets produced by established manufacturers and supply them from our Dammam warehouse.
Which ring joint profiles do you keep in stock?
R-oval, R-octagonal, RX and BX profiles in common sizes. Other profiles and materials can be sourced on request.
What information do you need for a quotation?
Flange size, pressure class, flange standard (ASME, API or EN), gasket style, winding and filler materials, and the quantity required.
Do you deliver outside Saudi Arabia?
Yes. We ship to customers across the GCC from Dammam, with documentation prepared for export.
