Outrigger Pads for XCMG Cranes Sizing Guide for Saudi Arabia

05 September, 2026 | Admin

Outrigger pads for XCMG cranes need to be matched to a wide tonnage range, since XCMG is one of the largest crane manufacturers supplying the Saudi market, with models extending from smaller rough-terrain units to some of the largest crawler cranes used on heavy industrial lifts in the region.

Where XCMG cranes are commonly used in KSA

• Wide general construction use across mobile crane classes • Heavy lift petrochemical and energy-sector projects on larger crawler models • Port and marine cargo handling on select models

Sizing outrigger pads for XCMG equipment

Given how wide XCMG’s tonnage range runs — from light rough-terrain units up to very large crawler cranes — pad sizing needs to be matched to the specific model and configuration rather than assumed. This is especially true for XCMG’s larger heavy-lift crawler cranes, which typically need interlocking mat solutions rather than single pads.

How to calculate outrigger pad size for XCMG cranes

The same basic formula applies across every crane brand: take the maximum outrigger reaction load from the load chart for your planned boom angle and radius, then divide by the safe bearing pressure of the ground at your site to get the minimum required pad area. Because XCMG’s range spans such a wide tonnage window, a pad sized correctly for a smaller rough-terrain unit will usually be far too small for one of the brand’s larger crawler cranes, so we always confirm the specific model before recommending a size.

Typical Saferig pad sizes for XCMG cranes

On the smaller end of XCMG’s rough-terrain and mobile range, UHMWPE outrigger pads commonly run from around 1m x 1m at 25mm to 30mm thick. For the larger crawler models used on heavy industrial lifts, pads frequently need to scale up to 1.5m x 1.5m or larger, in thicknesses up to 50mm, and sometimes interlocking mat systems rather than single pads. Diode Trading EST can also custom-cut pads where a specific XCMG float size doesn’t match a standard dimension.

Ground conditions across Saudi project sites

Many sites where XCMG cranes operate in the Kingdom involve variable ground — compacted fill, reclaimed coastal land, or loose desert sand — that can behave very differently under a concentrated outrigger load compared to solid rock or finished concrete. Correctly sized UHMWPE pads spread that load and reduce the risk of ground punch-through, which matters more as crane capacity and reaction loads increase.

Handling and storage for XCMG-scale pads

The larger pads used with XCMG’s bigger crawler cranes are heavier and typically need a two-person lift or basic mechanical assistance to reposition between outrigger points. We recommend keeping a dedicated pad set per outrigger position rather than shuffling a single set around the crane mid-job, and storing pads flat, stacked, and out of prolonged direct sun when not in use.

Working with Diode Trading EST

We supply Saferig UHMWPE outrigger pads with documented load ratings and Material Test Certificates, sized to your specific XCMG model and site conditions, with fast delivery across Saudi Arabia’s major industrial hubs. Share your crane’s load chart and ground type with our team before the job starts, and we’ll confirm the right pad size rather than leaving it to guesswork on site.

Get the right pad size before your next XCMG lift

If you’re planning a lift with an XCMG mobile, rough-terrain, or crawler crane anywhere in Saudi Arabia, send us the model, configuration, and ground type, and our team will confirm outrigger pad sizing and delivery timelines before you mobilize. This avoids the last-minute scramble for oversized mats when a bigger XCMG unit than originally planned turns up on site.

FAQ

What ground protection do XCMG's largest crawler cranes typically need?

For very large crawler cranes, track loading is usually spread across interlocking mats rather than discrete outrigger pads — see our interlocking crane mats guide for sizing guidance on that application.
