Bronze Filled PTFE Rods, Round Bars & Sheets (40% Bronze Filled PTFE)
Technical Specification
| Form | Rods, Sheets |
|---|---|
| Filler | 40% Bronze Powder |
| Key Properties | High wear resistance, excellent thermal dissipation, good load-bearing capacity |
| Typical Uses | Bushings, bearings, gears, wear rings under continuous load |
Key Benefits of Bronze Filled PTFE
Bronze Filled PTFE combines PTFE’s low friction with bronze powder filler for superior wear resistance and heat dissipation. Key benefits include:
- Highest Wear Resistance: Offers the best wear resistance among the common filled PTFE grades, suited to continuous-duty applications.
- Excellent Thermal Dissipation: Bronze filler conducts heat away from the friction surface better than unfilled or other filled PTFE grades.
- Good Load-Bearing Capacity: Handles higher loads reliably in bushings and bearings.
- Low Friction: Retains PTFE’s naturally low coefficient of friction for smooth operation.
Bronze Filled PTFE is the preferred grade for demanding, continuous-duty bearing and bushing applications.
Common Applications of Bronze Filled PTFE
- Bushings and bearings under continuous load
- Gears and wear rings
- High-speed rotating components
- Applications requiring heat dissipation at the friction surface
- Heavy-duty industrial machinery components
See our full PTFE Products range for other grades, or our PTFE Grades Guide to compare all available PTFE grades.
Bronze Filled PTFE Round Bars: Properties
Adding bronze powder to PTFE (typically 40% by weight in our standard grade) changes the material in ways that matter for moving parts. Bronze filled PTFE round bars and rods are chosen where virgin PTFE would creep or wear too quickly under load.
- Higher wear resistance: much longer life than virgin PTFE in sliding and rotating applications.
- Better compressive strength and lower creep: holds dimensions under load and pressure.
- Improved thermal conductivity: carries frictional heat away from the contact zone.
- Low friction retained: keeps the self-lubricating behaviour PTFE is known for.
Limitations to Check
Bronze reduces PTFE’s chemical resistance: the filler can be attacked by strong acids and some alkalis, and it makes the material electrically conductive and dark in colour. For aggressive chemicals, choose virgin or glass/carbon filled PTFE instead. See our virgin PTFE sheets and rods for comparison.
Typical Applications
- Hydraulic and pneumatic piston rings, guide rings and wear bands
- Bushings and bearings in oil-lubricated or dry running equipment
- Slide pads and wear strips for machinery
- Valve seats and seals in hydraulic systems
Background reading: polytetrafluoroethylene (PTFE) on Wikipedia.
Bronze Filled PTFE Round Bars: Why Buy from Diode Trading EST
- Stock in Dammam: short lead times in the Eastern Province and fast dispatch to Riyadh, Jeddah and project sites across KSA.
- Documentation: datasheets and a Material Test Certificate with every order for your submittal. Quality, environmental and safety management: ISO 9001, ISO 14001, ISO 45001.
- Trusted by major Saudi clients: Saudi Aramco, SABIC, NEOM, Red Sea Global, Zahid Group and Qiddiya.
- Local support: a Dammam-based team you can call, not a distant trading desk.
How to Order Bronze Filled PTFE Round Bars
- Send your size, grade and quantity to sales@diode.sa or use the quote form.
- We confirm availability from stock and send a quotation with the datasheet.
- On approval we dispatch from Dammam with the Material Test Certificate.
For bronze filled ptfe round bars enquiries, contact our team at sales@diode.sa.
Q1. What Is Bronze Filled PTFE Used For?
A. Bronze Filled PTFE is used for bushings, bearings, gears, and wear rings in continuous-duty, high-wear applications.
Q2. Why Choose Bronze Filled PTFE Over Other Grades?
A. Bronze Filled PTFE offers the highest wear resistance and best thermal dissipation among the common filled PTFE grades, making it ideal for demanding, continuous-duty bearing applications.
Q3. Does Bronze Filled PTFE Retain PTFE’s Low Friction?
A. Yes, it retains PTFE’s naturally low coefficient of friction while adding wear resistance and heat dissipation from the bronze filler.
Q4. Can You Machine Bronze Filled PTFE To Custom Sizes?
A. Yes, we offer CNC turning, milling, and cutting for Bronze Filled PTFE to your exact drawings and dimensions.
Q5. Do You Deliver Bronze Filled PTFE Across Saudi Arabia And The GCC?
A. Yes, Diode Trading EST supplies Bronze Filled PTFE with fast delivery across the Kingdom and the wider GCC.
