Outrigger Pads Saudi Arabia
Technical Specification
| Shape: | Round | Square | Customized |
|---|---|---|---|
| Size(mm): | 800 x 800 x 40 | Diam 650 x 60 | Customized |
| Thickness: | 40~200 mm | ||
| Loading: | 5T – 300T rated capacity (500T ultimate for SR-303010) — see Size Chart for per-size ratings | ||
| Density: | 0.941~0.985g/m³ | ||
| Molecular Weight: | 0.941~0.985g/m³ | ||
| Breaking Strength: | 42 Mpa | ||
| Shore Hardness D: | 65~70 | ||
| Handle: | Nylon Rope with Plastic Casing Pipe | ||
| Please Contact Us for More Information. | |||
Diode Trading EST is Saudi Arabia’s dedicated manufacturer and turnkey supplier of SafeRig™ UHMWPE outrigger pads and crane rubber stabilizer mats, engineered to protect the ground and stabilize mobile cranes, crawlers, concrete pumps, and heavy lifting equipment on any terrain across the Kingdom. As the leading crane outrigger pad stockist in Saudi Arabia, we hold ready stock across our size range for immediate dispatch — no wait for a production run.
Engineered Anti-Slip Surface Texturing
SafeRig™ outrigger pads feature a textured, high-friction surface designed to resist slippage and micro-sliding under load on uneven soils and wet or oily concrete foundations, helping keep the crane stabilizer foot securely in place.
Engineering Value for KSA Energy & Infrastructure Sites
- Extreme thermal & UV resilience: formulated to withstand intense solar radiation and ground temperatures exceeding 60°C across Yanbu and Riyadh without warping, cracking, or losing structural rigidity.
- Saudi Aramco & SABIC compliance: every pad is supplied with full material traceability sheets and product data certifications aligned with Saudi Aramco General Instructions (GIs), SABIC site safety requirements, and international BS 7121 lifting codes.
- UHMWPE and rubber options: our core UHMWPE range offers superior crush resistance and near-zero water absorption, while hybrid rubber-backed configurations are available for extra grip on tarmac and finished plant floors.
Aramco, SABIC & Site Safety Compliance
Procurement teams at Saudi Aramco, SABIC, and other KSA energy and petrochemical operators require documented proof that ground-protection equipment meets site-specific safety and material standards before it is approved for use. Every SafeRig™ outrigger pad shipped by Diode Trading EST is supported by the paperwork this approval process requires:
- Material traceability & test certificates (MTC) — batch-level documentation confirming the UHMWPE or rubber compound used in each pad, supporting clearance by third-party rigging safety auditors.
- Product data sheets & certificates of conformity — technical specifications aligned with Saudi Aramco General Instructions (GIs) and SABIC internal site safety requirements.
- BS 7121 lifting code alignment — pad selection and load ratings referenced against the international BS 7121 crane lifting operations code.
- Ground bearing pressure calculation support — our engineers help confirm the correct pad size and thickness for your specific crane configuration and site ground conditions ahead of a lift.
For the full library of our HSE and Quality Management documentation, including our Risk Assessment Procedure, Quality Management Policy, and Environmental Policy, see our Safety & Quality page.
Related Diode Trading EST Products
We also supply materials that complement outrigger pad protection on the same sites: Engineering Plastics — structural sheets, CNC wear bars, and raw polymer plates for high-abrasion environments; and PE Dock Bumpers — ultra-dense polyethylene impact protection for ports and docking facilities across Jeddah and Ras Tanura.
Technical Support & Verification
- Ground bearing pressure calculations — our engineers help match the correct pad size and thickness to your site conditions and crane configuration.
- Safety compliance documentation — written condition reports and material test certificates (MTC) to support clearance by third-party rigging safety auditors.
- Emergency replacement stock — held locally for rapid deployment if a pad is damaged during a project.
Download the Full Technical Datasheet
Get the complete SafeRig™ UHMWPE Outrigger Pads technical datasheet (Rev.02) — material specification (density, hardness, wear resistance, melting point), the full 25-size load capacity chart, and Material Test Certificate (MTC) details — in one PDF.
Need round pad specifications and city-by-city KSA coverage? See our Round Outrigger Pad Specifications & Saudi Arabia Coverage page.
Industry-Specific Names
Outrigger Pads go by many names — you might have heard them called crane outrigger pads, stabilizer pads, jack pads, support pads, lifting pads, or even ground mats for outriggers. No matter what you call them, they all do the same essential job: they help distribute the weight of heavy equipment and keep it steady, especially on soft or uneven ground. These pads are a key part of making sure lifting operations are safe and stable.
Product Configuration Options
SafeRig™ UHMWPE outrigger pads are available in the following configurations:
- Shape: Round, Square, or Customized
- Handle Type: Nylon rope with plastic casing pipe, for safe manual positioning
- Size: 25 standard sizes from 300 x 300mm up to 3000 x 1000mm (see the Size Chart below for the full range), plus fully customized dimensions on request
- Thickness: 40mm to 200mm
Crane Outrigger Pad Size Chart
| SN | SIZE | Load Capacity | Weight | Load Square Area | Product Code | Ultimate Load Capacity | Rope |
|---|---|---|---|---|---|---|---|
| 1 | 300 X 300 X 30mm | <5 tonnes | 2.58 kg | 0.09 m² | SR-333 | <7 | 1 |
| 2 | 400 X 400 X 40mm | <10 tonnes | 6.11 kg | 0.16 m² | SR-444 | <12 | 1 |
| 3 | 400 X 400 X 50mm | <12 tonnes | 7.64 kg | 0.16 m² | SR-445 | <15 | 1 |
| 4 | 500 X 500 X 40mm | <15 tonnes | 9.55 kg | 0.25 m² | SR-554 | <18 | 2 |
| 5 | 500 X 500 X 50mm | <20 tonnes | 11.94 kg | 0.25 m² | SR-555 | <22 | 2 |
| 6 | 600 X 600 X 40mm | <20 tonnes | 13.75 kg | 0.36 m² | SR-664 | <25 | 2 |
| 7 | 600 X 600 X 50mm | <25 tonnes | 17.19 kg | 0.36 m² | SR-665 | <30 | 2 |
| 8 | 600 X 600 X 60mm | <30 tonnes | 20.63 kg | 0.36 m² | SR-666 | <35 | 2 |
| 9 | 700 X 700 X 50mm | <35 tonnes | 23.40 kg | 0.49 m² | SR-775 | <40 | 2 |
| 10 | 700 X 700 X 60mm | <50 tonnes | 28.08 kg | 0.49 m² | SR-776 | <55 | 2 |
| 11 | 800 X 800 X 50mm | <50 tonnes | 30.56 kg | 0.64 m² | SR-885 | <60 | 2 |
| 12 | 800 X 800 X 60mm | <55 tonnes | 36.67 kg | 0.64 m² | SR-886 | <75 | 2 |
| 13 | 800 X 800 X 70mm | <75 tonnes | 42.78 kg | 0.64 m² | SR-887 | <90 | 2 |
| 14 | 800 X 800 X 80mm | <80 tonnes | 48.90 kg | 0.64 m² | SR-888 | <100 | 2 |
| 15 | 1000 X 1000 X 50mm | <75 tonnes | 47.75 kg | 1.00 m² | SR-10105 | <100 | 4 |
| 16 | 1000 X 1000 X 60mm | <80 tonnes | 57.30 kg | 1.00 m² | SR-10106 | <100 | 4 |
| 17 | 1000 X 1000 X 70mm | <100 tonnes | 66.85 kg | 1.00 m² | SR-10107 | <120 | 4 |
| 18 | 1000 X 1000 X 80mm | <120 tonnes | 76.40 kg | 1.00 m² | SR-10108 | <160 | 4 |
| 19 | 1000 X 1000 X 100mm | <160 tonnes | 95.50 kg | 1.00 m² | SR-101010 | <200 | 4 |
| 20 | 1200 X 1200 X 60mm | <180 tonnes | 82.51 kg | 1.44 m² | SR-12126 | <220 | 4 |
| 21 | 1200 X 1200 X 80mm | <220 tonnes | 110.02 kg | 1.44 m² | SR-12128 | <250 | 4 |
| 22 | 1200 X 1200 X 100mm | <220 tonnes | 137.52 kg | 1.44 m² | SR-121210 | <300 | 4 |
| 23 | 1500 X 1500 X 100mm | <250 tonnes | 214.88 kg | 2.25 m² | SR-151510 | <300 | 4 |
| 24 | 2000 X 1000 X 100mm | <280 tonnes | 191.00 kg | 2.00 m² | SR-202010 | <300 | 4 |
| 25 | 3000 X 1000 X 100mm | <300 tonnes | 286.50 kg | 3.00 m² | SR-303010 | <500 | 4 |
What Makes Our Outrigger Pads Better With Us?
- 1. The Best Quality in The Industry: We make the best-quality UHMWPE outrigger pads that guarantee high resistance and extend life.
- 2. Material Traceability & Compliance Documentation: Every pad ships with material traceability sheets and product data certifications aligned with Saudi Aramco GIs, SABIC site safety requirements, and BS 7121 lifting codes.
- 3. ISO Certified Company: Diode Trading EST is certified to ISO 9001 (quality), ISO 14001 (environmental) and ISO 45001 (occupational health & safety) management standards.
- 4. Custom Solutions Available: Designed to fit specific operational needs.
- 5. Quicker Deliveries: We ensure that the correct products are always given on time.
Purchase Quality Crane Outrigger Pads Online from Saudi Arabia
Diode Trading EST is a trusted name in Saudi Arabia regarding crane outrigger pads and other industrial safety and load-bearing requirements. Get in touch with us to discuss the crane outrigger pads we offer and get the right pad for your lifting operations! Feel free to reach out to us when you are looking for the best opportunities for Crane Outrigger Pads For Sale in Saudi Arabia.
Crane Outrigger Pads: The Best Choice for Safety and Effective Load Distribution
Safety and stability go hand in hand when it comes to lifting and construction. In Saudi Arabia, Diode Trading EST Limited sells pads that help distribute weight evenly while protecting the ground, serving as the foundation for lifting operations to be successful. At Diode Trading EST, we offer high-quality outrigger pads crafted from the finest polyethylene with incredible durability and unmatched load-bearing capabilities to satisfy the demands of industrial work in Saudi Arabia. Partnering with a successful Outrigger Mats Supplier In Saudi Arabia becomes mandatory.
FAQs – Crane Outrigger Pads:
- Where can I find crane outrigger pads for sale in Saudi Arabia?
The Saudi market can access lasting crane outrigger pads through Diode Trading EST, which maintains stable equipment positions and distributes heavy loads. - Do you supply outrigger mats for heavy equipment?
Our company serves as a prime outrigger mats supplier dedicated to providing strong mats made explicitly for cranes and heavy machinery in Saudi Arabia. - What types of outrigger pads do you offer?
The company functions as a reliable outrigger pad supplier throughout Saudi Arabia that provides different pad sizes and materials fitting multiple crane needs. - Why use a crane outrigger pad in Saudi Arabia?
You can rely on crane outrigger pads to ensure safety while also protecting the ground surface and achieving a stable position on irregular terrain.
Choosing an Outrigger Pad for Crane Stabilisation
The right outrigger pad for crane work spreads the outrigger load over enough ground to stay below its bearing capacity. As a crane pad supplier in Saudi Arabia, Diode Trading EST sizes Saferig pads from your crane model, maximum outrigger load and ground conditions, and supplies them from our Dammam warehouse with a Material Test Certificate (MTC). Use the outrigger pad calculator for a first estimate.
Buy Crane Outrigger Pads in Saudi Arabia
Diode Trading EST supplies Saferig™ UHMWPE crane outrigger pads from Al Khobar to contractors, crane rental companies and industrial sites across Saudi Arabia. The range runs from 300 × 300 mm pads for light equipment up to 3000 × 1000 mm pads rated for the heaviest outrigger loads, in 25 standard sizes. Whether you call them crane pads, outrigger pads, outrigger mats or outrigger plates, you can size yours in a minute with our free calculator.
- Rated load capacity listed for every size
- Material Test Certificate supplied with every order
- Not sure what size? Use the free Outrigger Pad Size Calculator or read our crane outrigger load calculation guide
- Need a custom size? Contact us
Buy the Best Crane Outrigger Pad in Saudi Arabia
Diode Trading EST offers the best crane outrigger pad in Saudi Arabia to provide maximum safety and stability while lifting the load. We support construction professionals, contractors, and engineers by offering them pressure-resistant, impact-resistant, and weather-resistant crane outrigger pads at a budget-friendly cost. Our products are manufactured by our renowned manufacturing partners. We are associated with the reputed manufacturers that produce our products using HDPE materials and high-strength UHMWPE. Our crane outrigger pads are durable, weather and chemical-resistant, non-conductive, easy to handle, and safe. So, why think much? Connect with us now.
Seeking the Best Jack Pads Manufacturer in Saudi Arabia? Contact Us!
Diode Trading EST is partnered with a reputable jack pad manufacturer in Saudi Arabia, who offers high-quality jack pads to us. We supply a wide range of jack pads to support the operations with enhanced stability and leveling. Our jack pads are designed for excellent performance. Our products blend superior grip, lightweight portability, and high compression strength. So, if you need to buy the best jack pads in Saudi Arabia, connect with us today.
Looking for the Best Lifting Pads Manufacturer in Saudi Arabia? Visit Us Now!
Being associated with the best lifting pads manufacturer in Saudi Arabia, Diode Trading EST supplies lifting pads to deliver safety, precision, and strength during operations. Our products are designed from premium-grade polymers. The lifting pads supplied by us are shock-resistant, provide load distribution, and vibration reduction during heavy-duty lifting operations. Our lifting pads are ideal for logistics, industrial, and construction environments. Connect with us today and buy the best lifting pads at affordable prices.
Outrigger Pads for Boom Trucks and Excavators
Boom trucks and excavators are two of the most common pieces of equipment we supply outrigger pads for in Saudi Arabia. A boom truck relies on its outriggers for the full stability of the lift — unlike a fixed crane, the truck chassis itself is not rated to take the load, so the pad under each outrigger is doing critical work every time the boom extends. Wheeled excavators fitted with stabilizer legs or a rear blade face the same problem on soft or uneven ground, particularly on sites with sabkha soil or recently backfilled trenches, where a concentrated point load can punch straight through the surface without a pad to spread it. We size SafeRig™ outrigger pads to match the outrigger footprint and ground-bearing pressure of both boom trucks and excavators, so operators get the same stability and ground protection they would from a larger mobile crane.
SafeRig™ UHMWPE vs. Wooden Outrigger Pads
Many contractors still fall back on timber matting under crane outriggers because it is cheap and locally available. UHMWPE pads cost more upfront, but the two materials behave very differently under repeated heavy loads:
- Moisture and chemical resistance — wood is porous and absorbs water, diesel, and hydraulic fluid, which weakens its structure over time. UHMWPE does not absorb moisture and keeps its load-bearing properties in wet, humid, or contaminated ground conditions.
- Structural consistency — timber has natural grain, knots, and moisture variation, so load-bearing capacity differs from board to board. UHMWPE sheets are manufactured to a consistent density and thickness, so every pad performs the same.
- Crack and splinter resistance — wood splits, splinters, and crushes under repeated point loading. UHMWPE resists cracking and denting, keeping a flat, stable bearing surface after repeated use.
- Reusable lifespan — a timber mat is often a single- or few-use item discarded once damaged. A correctly sized UHMWPE pad is designed for years of repeated deployment across multiple projects, lowering the effective cost per lift over time.
- Weight and handling — UHMWPE pads are lighter than an equivalent-strength timber mat of the same footprint, making them easier and safer for crews to position by hand using the built-in rope handle.
For short-term, one-off use on light loads, timber can still be adequate. For repeated deployment, wet or corrosive sites, or Aramco/SABIC-aligned projects where documented material traceability is required, UHMWPE is the more reliable choice.
Equipment That Requires Outrigger Pads
Outrigger pads are used under the stabilizing legs or tracks of a wide range of mobile lifting and heavy equipment, including:
- Mobile cranes (truck-mounted and all-terrain)
- Crawler cranes
- Rough-terrain cranes
- Boom trucks and knuckle-boom cranes
- Wheeled excavators fitted with stabilizer legs or a rear blade
- Concrete pumps
- Aerial work platforms (boom lifts and scissor lifts)
- Man lifts and utility trucks
Any equipment that extends outriggers, stabilizer legs, or jacks to lift or support a load benefits from a pad that spreads that point load across a wider footprint, reducing ground pressure and the risk of tipping or ground failure.
Outrigger Pad Sizing Guides
Outrigger Pads Supplier – FAQs
Q1. Where can I buy a crane outrigger pad in Saudi Arabia?
A. You can buy the best outrigger pad in Saudi Arabia at Diode Trading EST.
Q2. What are the best crane pads in Saudi Arabia?
A. The best crane pads in Saudi Arabia feature excellent material, durability, load-bearing capacity, ideal size and thickness, non-slip surface, weather-resistant, and much more.
Q3. Do you supply crane pads to manufacturers in Saudi Arabia in bulk for projects in Saudi Arabia?
A. Yes, we supply crane pads manufacturers in Saudi Arabia in bulk for projects in Saudi Arabia.
Q4. Do SafeRig™ outrigger pads carry third-party safety approvals for Aramco sites?
A. Yes. All configurations are supported by formal material traceability books, product sheets, and certified crush resistance values that fulfill Saudi Aramco GIs, SABIC internal rigging policies, and international BS 7121 lifting codes.
Q5. What is the maximum load tolerance your outrigger pads can handle?
A. Our standard square UHMWPE pad range handles up to 300 tonnes rated capacity (3000 x 1000 x 100mm, product code SR-303010), with an ultimate bearing limit of 500 tonnes. Smaller sizes are available from 5 tonnes upward — see the full Size Chart above for exact figures per pad size.
Q6. Are custom corporate engraving options or bespoke configurations available?
A. Yes. We provide custom CNC-milled profiles and corporate logo engraving directly into the face of the UHMWPE sheets to assist heavy fleet operators with inventory tracking and loss prevention on multi-contractor job sites.
Q7. What outrigger pad sizes do you supply?
A. Standard sizes run from 300 × 300 mm up to 3000 × 1000 mm, with rated capacities from 5 tonnes up to 300 tonnes, depending on size and thickness.
Q8. Which pad is right for my crane?
A. It depends on the outrigger load and the ground. Use our calculator or send us the load chart figure and the ground type.
Q9. Do you supply outside Al Khobar?
A. Yes, across Saudi Arabia. Contact us with your location.
Q10. Do you provide a Material Test Certificate?
A. Yes. A Material Test Certificate is supplied with every order.
